This Chalion QK Series 90HP Wheeled Tractor is big horsepower agriculture tractor. The tractors have compact structure, convenient operation, flexible steering, easy maintenance, 16F+8R gearbox, hydraulic steering, and dual action clutch.
Products Parameters
| 90HP | |||||
|---|---|---|---|---|---|
| Model | QLN-900 | QLN-904 | |||
| Engine | Rated power(kw) | 66.2 | |||
| Type | Water-cooled, in-line, four-stroke, direct injection | ||||
| Rotation speed(r/min) | 2300 | ||||
| Dimension | Wheel drive | 2WD | 4WD | ||
| Minimum using weight (kg) | 3560 | 3800 | |||
| Overall dimension(mm) | 4280*2085*2925 | ||||
| Wheel tread(mm) | Front wheel | 1520 | 1610 | ||
| Rear wheel | 1620 | ||||
| Wheelbase(mm) | Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â Â 2195 | ||||
| Minimum ground clearance(mm) | 450 | 370 | |||
| Gearbox | 10F+10R | ||||
| Tire | Front tire | 6.5-20 | 11.2-24 | ||
| Rear tire | 16.9-34 | ||||
| Steering type | Hydraulic power steering | ||||
| Working device | PTO shaft speed (r/min) | 760/1000(optional 540/760,540/1000,760/850) | |||
| Max lifting force(KN) | 14.2 | ||||
| Suspension type | Categoryâ…¡3-point linkage | ||||
