This Chalion QK Series 100HP Wheeled Tractor is big horsepower agriculture tractor. The tractors have compact structure, convenient operation, flexible steering, easy maintenance, 16F+8R gearbox, hydraulic steering, and dual action clutch.
Products Parameters
| 100HP | ||||
|---|---|---|---|---|
| Model | QLN-1002 | QLN-1004 | ||
| Engine | Rated power(kw) | 73.5 | ||
| Type | Water-cooled, in-line, four-stroke, direct injection | |||
| Rotation speed(r/min) | 2300 | |||
| Dimension | Wheel drive | 2WD | 4WD | |
| Minimum using weight (kg) | 3560 | 3800 | ||
| Overall dimension(mm) | 4280*2085*2925 | |||
| Wheel tread(mm) | Front wheel | 1520 | 1610 | |
| Rear wheel | 1620 | |||
| Wheelbase(mm) | 2195 | |||
| Minimum ground clearance(mm) | 450 | 370 | ||
| Gearbox | 16F+8R | |||
| Tire | Front tire | 6.5-20 | 12.4-24 | |
| Rear tire | 16.9-34 | |||
| Steering type | Hydraulic power steering | |||
| Working device | PTO shaft speed (r/min) | 760/1000 | ||
| (optional 540/760,540/1000,760/850) | ||||
| Max lifting Force at 610mm (KN) | 17.7 | |||
| Suspension type | Categoryâ…¡3-point linkage | |||
