The SINOTRUK HOWO 4×2 Mini Dump Truck is the ultimate solution for small to medium-scale construction, agricultural, and municipal projects. Engineered by China National Heavy Duty Truck Group (SINOTRUK), this light tipper truck combines the robust DNA of heavy-duty vehicles with a compact, highly maneuverable design. With a flexible loading capacity ranging from 3 tons to 10 tons, this diesel-powered 4×2 tipper offers an unbeatable balance of power, efficiency, and low price.
Whether you need to transport sand, gravel, construction waste, or agricultural products, the HOWO mini dump truck is built to handle tough jobs in tight spaces, making it the ideal partner for your business.
Key Features & Benefits
-
Powerful & Economical Engine: Equipped with a high-performance, fuel-efficient diesel engine (available options include the reliable Yunnei or WEICHAI powerplants). With horsepower ranging from 110HP to 150HP and high torque output, it delivers excellent pulling power for steep inclines and rough terrain while keeping operational costs low .
-
Versatile Loading Capacity (3-10 Tons): This chassis is designed to adapt to your needs. It operates efficiently at lighter 3-5 ton loads for urban deliveries and material transport, yet features the reinforced structure to handle maximum payloads of up to 10 tons for heavier construction materials .
-
Heavy-Duty Hydraulic Tipping System: Features a robust, hydraulic-powered dumping mechanism that allows for quick, safe, and efficient unloading of materials. The system is designed for durability and minimal maintenance, ensuring you spend more time working and less time repairing .
-
Rugged 4×2 Chassis & Durable Construction: Built on a reinforced SINOTRUK chassis with a high-strength steel frame, it withstands the rigors of daily loading and unloading. The dump body is constructed from thick, wear-resistant steel to resist corrosion and impact from rocks and debris .
-
Comfortable & Safe Operator Cabin: The ergonomic single-row cabin provides seating for 2-3 passengers with excellent visibility. Designed with driver comfort in mind, it includes features like power steering, an adjustable seat, and an efficient ventilation system, reducing driver fatigue during long shifts. Safety is prioritized with a dual-circuit air braking system and ABS options .
-
Exceptional Value (Low Price): As a leading Chinese manufacturer, SINOTRUK offers this mini tipper at a factory-direct, competitive price point. You get heavy-duty reliability without the heavy-duty price tag, ensuring a rapid return on investment .
Technical Specifications
| Specification Category | Detail |
|---|---|
| Drive Type | 4×2 (Left-Hand Drive / Right-Hand Drive Optional) |
| Emission Standard | Euro 2 / Euro 3 / Euro 4 (Customizable by market) |
| Engine Options | Yunnei / WEICHAI / CUMMINS (Typically 3.0L – 4.0L) |
| Horsepower (HP) | 110 HP – 150 HP |
| Transmission | Manual, 6-speed (WLY Series) or 8-speed/10-speed (FAST) options |
| Steering | Hydraulic Power Steering |
| Loading Capacity | 3 Tons / 5 Tons / 8 Tons / 10 Tons (Configurable) |
| Gross Vehicle Weight | 8,000 kg – 14,000 kg (Depending on configuration) |
| Cargo Body (LxWxH) | 3.2m – 4.2m length x ~2.0m width x 0.6m – 0.8m height (Customizable) |
| Body Material | Bottom: 8mm Thick Steel / Sides: 6mm Thick Steel (Optional thicker steel available) |
| Tipping Mechanism | Front-end hydraulic lift (Heavy-Duty Cylinder) |
| Front Axle | 2.7 Ton – 3.6 Ton Capacity |
| Rear Axle | 7.2 Ton – 8 Ton Capacity (Single reduction) |
| Tires | 8.25R16 / 9.00R20 (6 wheels + 1 spare) |
| Fuel Tank Capacity | 120L – 200L |
| Brake System | Dual-circuit air brake / Air-assisted hydraulic brake |
| Cab | Single row, 2-3 seats (SINOTRUK 2080 or similar design) |
| Overall Dimensions (LxWxH) | 5,995mm x 2,200mm x 2,550mm (Varies by body size) |
| Wheelbase | 2,850mm – 3,800mm |
Applications
This versatile tipper truck is perfectly suited for a wide range of industries:
-
Construction: Transporting sand, gravel, bricks, and soil on building sites.
-
Mining & Quarrying: Hauling ore and aggregates in small to medium mines.
-
Agriculture: Moving grain, feed, fertilizer, and harvested crops.
-
Municipal Works: Street cleaning, waste collection, and road maintenance.
-
Landscaping & Farming: Transporting dirt, mulch, and livestock materials.
Why Choose the SINOTRUK HOWO Mini Tipper?
In a market crowded with light trucks, the SINOTRUK HOWO stands out due to its proven reliability and global parts availability. It is not just a light truck; it is a scaled-down version of the legendary HOWO heavy-duty trucks known worldwide for their durability. By choosing this model, you benefit from:
-
Low Initial Investment: Factory prices make it accessible for start-ups and small businesses.
-
Low Maintenance: Simple, proven mechanics mean fewer breakdowns and easy repairs.
-
High Resale Value: The SINOTRUK brand holds its value in used truck markets globally.
Customization & Ordering
We offer full customization to meet your specific operational requirements. You can choose:
-
Different engine horsepower and emission standards (Euro 2, 3, 4).
-
Various cargo body sizes and material thicknesses.
-
Optional add-ons: Air conditioning, ABS, spare tire carrier, and more.
Contact us today for a factory-direct quote on the SINOTRUK HOWO 4×2 10 Ton Mini Dump Truck and experience the perfect blend of power, price, and performance!
